Slots, milling, contour and rout-outs have to be indicated clearly to be processed correctly in production.

Make sure the width of the lines is at least 1 mil or larger. The board is milled/cut to the middle of the line, so thickness of the line does not impact the result. Making the thickness of the lines a non zero number will reduce problems down the road with external gerber viewers. Drawing Cut Outs and Slots. The size of the slots can be indicated in text together with tolerances ( if needed). Indicate only one border in your mechanical layer. If you want a round shaped PCB then we expect a round shaped contour, not a round shaped PCB inside a square box, as this will result in a square shaped PCB Examples. Acceptable contour file indicating slots. The Board Shape is used by Altium Designer when: Splitting a board into multiple board regions. Placing bending lines on a flex board region. Defining the extents of the power planes for plane edge pull back. Splitting power planes. Calculating the board edge when outputting design data to other tools; When a new board file is created, the. Altium Board Slots, aqua casino boston, poker 480x320, holdem la leyenda. Your board shop does not have a square drill bit, and can not drill a square hole. That is why Altium shows the hole as round. You can put a square pad around a round hole or slot, but it's simply not physically possible to drill a square hole. $ endgroup $ – The Photon Sep 14 '18 at 5:43.

Do not indicate them in your cupper layers or textprint layers
Do not indicate them by putting text outside your layout
Do not indicate them by adding a textfile or any other document together with your datafiles.

But

Do indicate the slots, milling and routing information into a mechanical layer. A mechanical layer consists of the border of the PCB, together with any other mechanical finishings like extra milling, routing or slots.
The size of the slots can be indicated in text together with tolerances ( if needed).
Indicate only one border in your mechanical layer. If you want a round shaped PCB then we expect a round shaped contour,
not a round shaped PCB inside a square box, as this will result in a square shaped PCB…

Examples

Acceptable contour file indicating slots. The contour layer has to have the same offset as the other copper layers in order to align copper and routing together.
Properly aligned layers – correct offset to the contour layer
Not correctly aligned layers – incorrect offset to the contour layer
Example of acceptable drillmap file indicating slots
- Note that the contour layer is drawn with a normal linewidth (0.2 mm). Do not use the thickness of the router to avoid confusion about the correct dimensions of the PCB. We consider the midpoint of the line as indicator of the correct dimension.
- Slots will be PTH when copper pads are present on top and bottom layer (comparable rule as with normal plated through holes).
- Slots will be NPTH when no copper pads are present on top and bottom layer (comparable with normal non-plated through holes).
- When you need a NPTH slot and copper pads are present, then you will have to indicate this clearly in your design – see example below:
